0.000-4.000Abs |
Absorbance Range |
0.001Abs(display),0.0001Abs(calculation) |
Resolution |
±0.1% or ±0.005Abs |
Accuracy |
Standard with 96-well or other kind of microplate and strip |
Type of Microplate |
405, 450, 492, 630nm, 4 more filters optional(from 400-700nm available on special order) |
Wavelength |
0.000-2.500Abs |
Measurement range |
8-channel optic fiber system |
Optic System |
Halogen lamp |
Light Source |
405, 450, 492, 630nm, 4 more filters optional |
Wavelengths |
± 1nm |
Wavelength Accuracy |
<8nm |
Band width |
ABS, %ABS, Cut-Off, Single Standard, Curve, Multi-Percent, Percent Log, Linear, Exponential, Power, 4PL Regression |
Calculation Method |
5 seconds for 96 well plate (single wavelength) |
Reading Speed |
Shaking time and speed adjustable |
Shaking Plate |
PC operation, bidirectional communications |
Operation |
More than 100 programs, up to 100,000 test results |
Memory |
RS-232, USB, SD card interface |
Interface |
6” LCD (with touch screen function) |
Display |
Touch panel or mouse |
Input |
Internal printer; External printer (optional) |
Output |
AC 110V - 220V ± 10%, 50-60Hz |
Power supply |
9KG |
Net Weight |
460×330×200 |
Dimensions L × W × H(mm)
|
